Hathor Modular Steel Solar Canopy
Built Wide. Built Ready. Built to Power the Future.
Hathor transforms parking areas into intelligent energy hubs. With an 11-metre span and a raised central kerb designed for EV integration, it combines bold engineering with high-output solar generation, ready for today’s vehicles and tomorrow’s demands.
Hathor Modular Steel Solar Canopy
Product Ref: KSCC-EFSC-HAT
Canopy Type: Steel Embedded Foundation Canopy
canopy includes
(available without solar panels/electrical items if required)
Supplied in Kit Form or Fully Installed
The Hathor Steel Solar Canopy is an 11-metre-wide, double-row mono-pitch system engineered for performance and infrastructure integration. Spanning two back-to-back 5 metre parking bays, it incorporates a 1 metre raised central kerb designed specifically for EV charge points and concealed cable routing.
Its 10° single-slope roof ensures reliable solar generation and efficient rainwater management, while maintaining full vehicle access beneath.
The 12.5 metre starter module supports 60 Aiko 670W panels, delivering 40.20 kW of peak capacity. Each additional module extends the canopy by approximately 10 metres, covering a further eight parking bays and supporting 40 additional panels, generating 26.80 kW per section.
Available in kit form or as a turnkey installation, Hathor is built to scale with evolving energy and transport needs.
Available in kit form or fully installed. This solar canopy comes with solar panels. Our solar canopies and carports can be supplied without solar panels and electricals, should you wish to fit your own. Options can include self-contained systems with Energy Storage (EESS), CCTV Cameras, Internal and/or External Lighting and of course EV charging (EVCPs). Using our amazing range of EV charge products. Colour options are available as well as ideas for branding and/or offering advertising space.
The Hathor Modular Steel Solar Canopy is manufactured in the UK using British steel wherever possible. The primary structural framework is formed from universal beams, typically 533 x 210 x 92 sections, selected to provide structural integrity, stiffness, and long-term durability under wind and snow loading conditions.
Roof purlins are manufactured from 200 × 100 × 6.3 mm rectangular hollow section, RHS steel, spanning between primary beams to support the roofing system and photovoltaic array. All structural steelwork is hot-dip galvanised to a minimum average coating thickness of 85 microns in accordance with BS EN ISO 1461, providing long-term corrosion protection.
For enhanced aesthetic finish and additional surface durability, canopies can be spray-painted over the galvanised coating. Anthracite grey is a popular specification choice; any RAL colour can be provided to suit site requirements or planning conditions. Roof sheets are high-performance plastisol-coated steel roofing sheets, supplied in a range of colours to complement the chosen steel finish. The roofing system is designed for long service life, weather resistance, and low maintenance performance.
For a quotation, supply only or fully installed, please contact us.
Canopy Width
11.000 meters
Max Module Span
10.000 meters
Standard End Cap
1.000 meters
Extended End Cap
2.500 meters
Solar Panels per Module
36 solar panels
kW Rating per Module
24.120 kW
Solar Panels per Extended End Cap
9 solar panels
kW Rating per Extended End Cap
6.030 kW
Parking Bays per Module
8 standard bays
Parking Bays per Extended End Cap
2 standard bays
If you have any questions, would like an informal chat or require a formal quote please do contact us. We welcome all enquiries...
view product
contact us
What is Included:
- All Required Pre-galvanised Steelwork
- Fully Bolt Together Steel Frame
- All Required Fixings Are Included
- Ground Anchor (requires embedding in concrete)
- Includes (available without panels if required)
- All Required Electrical Cables & Connectors Are Included (up to GRP 20m from structure)
- Clear Assembly Instructions With Video (installation service available)
- Meets All UK Health & Safety Requirements
Optional Extras:
- Full Installation Service
- EV Chargers (see our fantastic range of EVCPs)
- GRP Housing Box (to hold fuse box/inverter/isolators)
- Inverters / Charge Controllers
- Electrical Energy Storage Systems (EESS)
- Security Cameras
- Internal & External LED Lighting (can be set on a timer, a PIR or a light intensity sensor)
- Steel Gutters & Drainage
- Galvanised and/or Painted Colour Options
- Corporate Branding & Advertising
Hathor was one of the most revered goddesses of ancient Egypt, associated with renewal, protection, and the life-giving power of the sun. Often depicted with a solar disk between her horns, she symbolised nourishment, connection, and the daily rebirth of light.
As Lady of the Eastern Horizon, she welcomed the rising sun and guided its return to the sky, representing continuity and sustainable life.
The Hathor Steel Solar Canopy reflects that same principle, capturing the sun’s energy at first light and transforming it into enduring power for modern infrastructure.
BRANDING
For outside an office building or a public car park? Brand this product for your business or offer advertising space, both are available.Installation
Our Carports & canopies come with clearly written and video instructions. However, a full installation service is available.A Note On Parking Bay Sizes:
When assessing the area needed for staff and customer parking, it should be noted that the current UK norm for parking spaces is 2.4m wide by 4.8 m long. However please note that several models of modern vehicles are more than 4.8m long. The recommended space for manoeuvring (roadways) between bays is 6m.
These dimensions are neither minimum nor written in tablets of stone and may be revised to suit your particular needs, but remember that good access and wider bays aid efficient use of the parking area and are much more pleasant for your customers to use.
For more information on parking in the UK visit: The British Parking Association
click image to view larger
Bay Sizes For Motorists With Disabilities: The BSI British Standards Code provides some guidance as to what is required - disabled access parking spaces should be 2400mm x 4800mm with a 1200mm wide marked access zone between spaces and a 1200mm wide safety zone for boot access. Government guidelines (Inclusive Mobility published by DfT) recommend that 6% of parking be allocated to disabled people unless otherwise covered by local planning regulations. The guidance also recommends how to identify these spaces, with special markings and signage.
click image to view larger
EV Charger Bay Sizes: It is recommended that additional access zones between parking bays be left for EV charging. This allows some vehicles to plug and charge from the side. These bays should also be marked and include eye-level signage.
Disabled EV Charger Bays: As the number of electric vehicles in the UK grows as will the requirement for EV charger bays. There are currently no guidelines on providing disabled parking bays with EV chargers so although not essential we recommend creating EV charger bays with the required 1.2m marked area between the bays and thus automatically making all your EV charger bays suitable for people with disabilities as well as allowing space for vehicles that charge from the side.
KaraSolar use a standard parking bay size of 2.50m wide by 5.00m long
To reduce the potential risks, we recommend clearly displaying canopy height restrictions with signs at eye level located at the car park entrance and on the canopies themselves. Allowances should also be made at the ends of the structures to prevent high-sided vehicles from colliding with the canopy while manoeuvring. Where possible, implementing a height restriction at the point of entry is an even more effective solution.
KaraSolar Canopies Height Clearance is a Standard 2.50m
A Note On Vehicle Heights:
When planning the placement of solar canopies, it is essential to consider the maximum height of vehicles that may use the car park, not just those parking under the canopy. Thought should be given to high-sided vehicles manoeuvring around the structures. Our solar carports and canopies are typically designed with a vehicle clearance height of 2.50 metres. We can increase this height, however, this would increase the overall canopy height and potentially create planning issues and/or lower the roof pitch therefore lowering the solar performance. An increase in canopy height may also make it necessary to increase the canopy's specifications.
Domestic Vehicles: All our Solar Canopies and Carports comfortably accommodate all vehicles intended for domestic use. One of the tallest in this category, the Land Rover Discovery, stands at 2.00 metres high. The vehicles shown in most of our drawings are the Jaguar F-Pace (1.66 metres high) and/or the Jaguar I-Pace (1.56 metres high).
Commercial Vehicles: If the car park is frequently used by commercial vehicles, a 2.50-metre clearance could potentially cause issues. Common commercial van heights include:
H1 - Standard - up to 2.50m
H2 - High Top - up to 2.90m
H3 - Super High Top - up to 3.20m
For example, the height of a VW Crafter can range from 2.30 metres to 3.20 metres high, depending on the model. Of course box vans and lorries can be even higher.
Our Carports and Canopies can be supplied without panels and electricals if you would like to fit your own.
system includes:
AIKO COMET: 2U72 Mono-Glass645W-670W Solar Panels
Second-generation comprehensive upgrade Higher power output | Lower BOS | More green electricity
- 25-Year Product Warranty (extended warranty included)
- 30-Year Performance Warranty
- Efficiency: up to 24.8%
- Low performance degradation: ≤1% in the first year, and ≤ 0.35%/year in the following years
- Premium warranty: 15-year product warranty， extendable to 25-year and 30-year performance warranty
- Better temperature coefficient: -0.26%/°C
- For the same area, the installed capacity is 5.0%+ higher than TOPCon and 12.5%+ higher than PERC.
- For the same area, the power generation is 7%+ higher than TOPCon and 15%+ higher than PERC.
- The BOS cost per watt is 4.76% lower than TOPCon and 11.11% lower than PERC.
- Lower O&M cost
- High temperature restriction and micro-crack resistance, front grid free, ensuring roof safety, reducing module failure rate.
- The same DC capacity with connection points reduced by about 5.5%.
Please Note: Our systems are available in kit form or fully installed. You may also require a charge controller, inverter or smart meter depending on where you are sending the power from these panels. If you are unsure please speak with your electrician or please do get in touch.
Examples of Hathor Modular Steel Solar Canopy Parking Layouts, Dimensions, Solar Capacity, and Expected Performance
All KaraSolar solar canopies and carports are fully modular. While the widths can be adjusted slightly to suit specific project needs, the modular design ensures they can be extended to any desired length, providing flexibility for future expansion. To achieve the most cost-effective solution (in terms of kW per £), we recommend maximising the canopy spans.
The solar estimates provided below are based on installing the specified canopies, oriented south-facing at Winchester Park and Ride. For detailed information on how we calculate solar performance, please visit our section on OpenSolar.
*Performance charts are estimated using OpenSolar.
Independently Verified, Class-Leading Design Accuracy
OpenSolar has engaged with some of the most trusted experts in the industry to provide independent, 3rd party assessments of the accuracy of OpenSolar’s design tool.
for more information...
Warranties & Guarantees
What your system can include...
Colour Range
LED Lighting
Guttering
Security Cameras
Parking Design
All Our Solar Carports and Canopies
are Designed and Made in the UK.
Supporting British Manufacturing, Minimising
Environmental Impact and Creating British Jobs.
We use ‘British Steel’ & 'British Timber’
EV Chargers from Rolec are designed and made in the UK.
Inverters & Batteries from UK company Rayleigh Instruments.
Roofing sheets from British company Cladco
We Love to get JAZZY!
Our solar carports and canopies are available in a range of painted colour finishes. However, if you're looking for something more unique, we love getting creative. From timber inserts set into the steel frames, with the option to have your logo burned into the timber, to translucent resin panels illuminated by LEDs, we’re always excited to collaborate with our clients to create a design that perfectly complements the location and enhances its aesthetic appeal.
Add Rolec EV Chargers To Your Solar Structure
From EV charging solutions for the home, commercial locations, workplaces and fleets, Rolec EV provides an exceptional service led by a team of dedicated experts. Whilst offering the UK’s largest range of AC Fast and DC Rapid charging points, Rolec has the reputation for delivering cost-effective, scalable solutions to suit all budgets and requirements.
The extensive range of Rolec EV charging points has proven to be a success amongst many businesses and organisations, with thousands opting for Rolec’s smart OCPP compliant back office management system.
Rolec also manufactures a vast range of OZEV grant-funded charging points, allowing both EV drivers and businesses to take advantage of significant cost savings when purchasing and installing EV charging points at their homes and workplaces.
Rolec have an incredible range of EV Chargers, we recommend The QUANTUM EV charging pedestal with the Hathor Modular Steel Solar Canopy.
The QUANTUM EV charging pedestal is a sophisticated and resilient EV charging point, providing a combination of durability and impeccable design for all locations. This charger’s integrated LED amenity lighting also provides greater visibility of the charging bays and surrounding areas.
This future-proof OCPP compliant pedestal can offer a simple plug & charge or pay-to-charge solution via the EV driver’s smartphone and/or RFID card/fob through any chosen OCPP back-office management system.
For more information on having EVCPs installed with your solar carport or canopy please do CONTACT US. We welcome all enquiries.
