Design Proposal
Timber Solar Canopy
Glebe Cottage – Yelverton – PL20 6LU
Skip Directly To
The Project
our ref:
KS/CCI-00191
Client
Client Name:
Martin Emmott
Client Address:
Glebe Cottage,
Burrautor Road,
Dousland,
Yelverton,
PL20 6LU
Client Project Ref:
N/A
Client Brief
Design, supply, install timber solar canopy to single phase domestic property.
Welcome to your KaraSolar Design Proposal
KaraSolar are revolutionising the way carparks are utilised by transforming them into sustainable powerhouses. Our innovative solar canopies not only provide shade and protection for vehicles but also harness the sun’s energy to generate clean, renewable power.
Why Choose Our Solar Canopies?
- Eco-Friendly Energy: Embrace a greener future with our solar canopies that reduce carbon footprints and promote sustainable energy use.
- Cost Savings: Lower your energy bills and potentially earn through energy credits with our efficient solar technology.
- Enhanced Carpark Experience: Our canopies offer shade and protection from the elements, improving comfort for your customers or employees.
- Aesthetic Appeal: Modern and sleek designs that enhance the visual appeal of your carpark while demonstrating your commitment to sustainability.
A Note On Parking Bay Sizes:
When assessing the area needed for staff and customer parking, it should be noted that the current UK norm for parking spaces is 2.4m wide by 4.8 m long. However please note that several models of modern vehicles are more than 4.8m long. The recommended space for manoeuvring (roadways) between bays is 6m.
These dimensions are neither minimum nor written in tablets of stone and may be revised to suit your particular needs, but remember that good access and wider bays aid efficient use of the parking area and are much more pleasant for your customers to use.
Bay Sizes For Motorists With Disabilities: The BSI British Standards Code provides some guidance as to what is required - disabled access parking spaces should be 2400mm x 4800mm with a 1200mm wide marked access zone between spaces and a 1200mm wide safety zone for boot access. Government guidelines (Inclusive Mobility published by DfT) recommend that 6% of parking should be allocated to disabled people, unless otherwise covered by local planning regulations. The guidance also recommends how to identify these spaces, with special markings and signage.
For more information on parking in the UK visit: The British Parking Association
EV Charger Bay Sizes: It is recommended to leave additional access zones between parking bays intended for EV Charging. This allows for some vehicles that plug and charge from the side. These bays should also be clearly marked and include eye-level signage.
Disabled EV Charger Bays: As the number of electric vehicles in the UK grows as will the requirement for EV charger bays. There are currently no guidelines on providing disabled parking bays with EV chargers so we highly recommend creating EV charger bays with the required 1.2m marked area between the bays and thus automatically making all your EV charger bays suitable for people with disabilities.
Transform your carpark into a beacon of sustainability
We are dedicated to providing top-quality solar canopy solutions tailored to meet your specific needs. Our team of experts handles everything from design and installation to maintenance, ensuring a seamless and hassle-free experience.
A Note On Vehicle Heights:
When planning the placement of solar canopies, it is essential to consider the maximum height of vehicles that may use the car park, not just those parking under the canopy. Thought should be given to high-sided vehicles manoeuvring around the structures. Our solar carports and canopies are typically designed with a vehicle clearance height of 2.50 metres. We can increase this height, however, this would increase the overall canopy height and potentially create planning issues and/or lower the roof pitch therefore lowering the solar performance. An increase in canopy height may also make it necessary to increase the canopy's specifications.
Domestic Vehicles: All our Solar Canopies and Carports comfortably accommodate all vehicles intended for domestic use. One of the tallest in this category, the Land Rover Discovery, stands at 2.00 metres high. The vehicles shown in most of our drawings are the Jaguar F-Pace (1.66 metres high) and/or the Jaguar I-Pace (1.56 metres high).
example vehicle Jaguar F-Pace
Commercial Vehicles: If the car park is frequently used by commercial vehicles, a 2.50-metre clearance could potentially cause issues. Common commercial van heights include:
- H1 - Standard - up to 2.50m
- H2 - High Top - up to 2.90m
- H3 - Super High Top - up to 3.20m
For example, the height of a VW Crafter can range from 2.30 metres to 3.20 metres high, depending on the model.
To reduce the potential risks, we recommend clearly displaying canopy height restrictions with signs at eye level located at the car park entrance and on the canopies themselves. Allowances should also be made at the ends of the structures to prevent high-sided vehicles from colliding with the canopy while manoeuvring. Where possible, implementing a height restriction at the point of entry is an even more effective solution.
Notes about our PRIVACY POLICY
We take your privacy and the safety of your information very seriously. We will never publicly publish your personal details, and all places that may contain your personal information will always be password protected. Any and all personal information is treated in accordance with The Data Protection Act 2018. We will never share your information with any third party with the exception of where required in order to attain quotes or services related to your project. We will delete your personal details from our system at any time you request with the exception of where we are required to do so for legal reasons such as warranties and invoices. For more information on how we treat your personal data please see our PRIVACY POLICY.
The Site
PL20 6LU
Site Address
Site Client:
Martin Emmott
Site Address:
Glebe Cottage,
Burrautor Road,
Dousland,
Yelverton,
PL20 6LU
Notes On The Site
|
Site Survey: |
This budget estimate and design proposal are intended as a guide to show our recommendations for design and an estimate of the cost. We have made several assumptions; a site survey would be required to confirm all of the following details. |
|
Current Site Use: |
Private Driveway |
|
Current Site Surface: |
Unknown |
|
Finished Site Use: |
Private Driveway |
|
Finished Site Surface: |
TBC |
|
Site Suitability: |
The proposed site falls within the required parameters for KaraSolar Timber Canopies in terms of windspeed, snow load, altitude, and environmental exposure. |
|
Underground Services: |
We would require a site services plan of the proposed site location before confirmation to establish the existence of any underground services. KaraSolar can undertake a services survey on the client’s behalf during our initial site survey. |
|
Drainage: |
We would require a site services plan to establish the location of any existing drainage services to establish the best method of connecting the proposed structures to a suitable drainage system. KaraSolar can undertake a services survey on the client’s behalf during our initial site survey. |
|
Solar Shading: |
It would appear there are no shading issues to the canopy, we will confirm during a site visit. If it is necessary for any trees to be destroyed during this project, KaraSolar will undertake to plant at least double the number of trees of a suitable species on the same or alternative site. |
|
Known Site Hazards: |
Security/Safety Fencing Required. Underground Hazards: Unknown Above Head Hazards: Unknown |
|
Waste Removal: |
KaraSolar will ensure the site is left clean, tidy and ready for use. All waste materials will be recycled wherever possible. |
|
Schedule of Works: |
To be confirmed. |
|
Electrical Connection: |
Connection to existing electrical system TBC |
|
DNO Approval |
DNO Approval would be required before connecting this system to the grid. KaraSolar can take care of this on your behalf. It is highly recommended to get either approval or upgrade costs from the DNO before any contract is signed. |
|
Planning Approval: |
PV systems on solar carports may not mean the system is automatically permitted without prior planning approval. Please check with your local planning office. KaraSolar Ltd. shall provide the information, drawings and layouts sufficient to allow a Lawful Development Certificate or full planning approval to be applied for. Should you require any help with your planning application we are very happy to recommend the following specialists. Andrea Fox |
click image to view larger
Site Assumptions
Our initial comments, proposals and quotes are intended as a guideline only and are subject to a site survey. We have made some assumptions in order to calculate this proposal. You will find a list of these assumptions and the end of 'The Proposal'.
The Structure(s)
Version 1.01
Notes On The Structures - Version 1.01
click image to view larger
click image to view larger
Structure Ref:
KS/CCI-00191/A
Canopy Model Type:
Lugh
Width of Canopy:
6.00 m
Length of Canopy:
7.50 m
Azimuth of Canopy:
210° (degrees from north)
Pitch of Canopy Roof:
10°
Number of Parking Bays:
2
Number of Support Sections:
7
Number of Solar Panels:
15
Solar Panel Type:
JA Solar 595W Mono PERC Half-Cell MBB Traceable LB MC4
Total Wp Rating:
8.925 kW
Estimated Annual Generation:
9,166 kWh*
(*see below for details on how we calculate these estimates)
click above image to view larger or the button below to download a PDF
All KaraSolar Canopies and Services Meet UK Building Standards and Eurocodes.
The Eurocodes are a set of structural design standards, developed by CEN (European Committee for Standardisation), to cover the design of all types of structures in steel, concrete, timber, masonry and aluminium. In the UK, they are published by BSI under the designations BS EN 1990 to BS EN 1999; each of these ten Eurocodes is published in several Parts and each Part is accompanied by a National Annex that implements the CEN document and adds certain UK-specific provisions.
What your system can include...
Colour Range
LED Lighting
Guttering
Security Cameras
Parking Design
All Our Solar Carports and Canopies
are Designed and Made in the UK.
Supporting British Manufacturing, Minimising
Environmental Impact and Creating British Jobs.
We use ‘British Steel’ & 'British Timber’
EV Chargers from Rolec are designed and made in the UK.
Inverters & Batteries from UK company Rayleigh Instruments.
Roofing sheets from British company Cladco
We Love to get JAZZY!
Our solar carports and canopies are available in a range of painted colour finishes. However, if you're looking for something more unique, we love getting creative. From timber inserts set into the steel frames, with the option to have your logo burned into the timber, to translucent resin panels illuminated by LEDs, we’re always excited to collaborate with our clients to create a design that perfectly complements the location and enhances its aesthetic appeal.
The Solar System
Version 1.01
Notes On The Solar System - Version 1.01
Please Note: We have picked these panels to maximise solar performance for the available space. Other Solar panels are available if you would prefer a different type. We also frequently install REC or Jinko panels with a 25-year product warranty. Please speak with your project manager for more information.
Project includes 15 x JA Solar 595W Mono PERC Half-Cell MBB Traceable LB MC4
Total Project Solar Power Rating
8.925 kW
Solar PV Panels:
The JA Solar 595W Mono N-Type Bifacial Double Glass High Efficiency LB MC4 (JAM72D40 575-600/MR) solar panel is a 595W monocrystalline bifacial module with 144 Mono-16BB cell technology. JA Solar offers a high-efficiency module, which, thanks to its half-cell configuration, offers high power output, better temperature coefficient, lower efficiency loss against shading, and higher resistance to mechanical loads. JA solar panels come with a 12-year product warranty and a 25-year linear output warranty.
DURABLE, DUST & WATER RESISTANT: JA solar's monocrystalline modules offer an excellent response even in extreme temperature conditions or low solar radiation, such as on cloudy days, at dawn, or dusk. The advanced, textured glass surface of the photovoltaic cells offers unsurpassed resistance to high levels of sea salt, ammonia, dust, or sand.
MORE RELIABLE:
- Higher power generation - better LCOE.
- N-type with very low LID.
- Better weak illumination response.
- Better temperature coefficient.
- Comes with a 12-year product warrant and 30-year linear power output warranty.
- Efficiency 22.5%.
Utility savings based on switch from Energy Direct Jul23v3 to Intelligent Octopus Go South Western – Jul 24
Your projected energy cost is calculated by considering a 7.0% increase in energy cost each year, due to trends in the raising cost of energy. This estimate is based on your selected preferences, current energy costs and the position and orientation of your roof to calculate the efficiency of the system. Projections are based on estimated usage of 7533 kWh per year, assuming Energy Direct Jul23v3 Electricity Tariff.
Your electricity tariff rates may change as a result of installing the system. You should contact your electricity retailer for further information.
The following performance charts are based on installing this system at:
Glebe Cottage,
Burrautor Road,
Dousland,
Yelverton,
PL20 6LU
Version 1.01
Total Number of Solar Panels:
15
Solar Panel Type:
JA Solar 595W Mono PERC Half-Cell MBB Traceable LB MC4
Total Wp Rating:
8.925 kW
Total System Estimated Annual Generation:
9,166 kWh*
(for more details on each individual solar array see below.)
Your projected annual energy usage is currently set to 7,533 kWh.
If you would like to change the projected usage amount please just let us know.
Your projected annual solar power generation: 9,166 kWh.*
See below for more information on how our solar performance estimates are calculated.
The system performance chart is an estimate of what you could expect your solar system to generate.
- The orange bar represents the expected kWh per day your system should create
- The grey background represents your current (or projected) kWh power usage.
The more accurate you are able to provide current energy usage data the more accurate we can estimated the impact of installing solar. For example, determining energy consumption curves allows us to calculate battery requirements and more accurate bill savings. Please speak with your project manager to increase the accuracy of these projections.
Structure Ref:
KS/CCI-00191/A
Canopy Model Type:
Lugh
Number of Solar Panels:
15
Azimuth of Canopy:
210° (degrees from north)
Roof Pitch of Canopy:
10°
Solar Panel Type:
JA Solar 595W Mono PERC Half-Cell MBB Traceable LB MC4
Total Wp Rating:
8.925 kW
Estimated Annual Generation:
9,166 kWh*
(*see below for details on how we calculate these estimates)
click image to view larger
*Performance charts are estimated using OpenSolar.
Independently Verified, Class-Leading Design Accuracy
OpenSolar has engaged with some of the most trusted experts in the industry to provide independent, 3rd party assessments of the accuracy of OpenSolar’s design tool.
for more information...
System Also Includes - Version 1.01
1 x Sunsynk 8.8kW ECCO Hybrid Inverter
Reduce your electricity costs by managing power from various energy sources, including solar panels, batteries, the national electricity grid, a generator or even a wind turbine – all with a Sunsynk Hybrid Inverter. It’s ideal for home and business and scalable so that you can expand it as required.
View/Download Component DataSheet
The SunSynk 8.8kW AC ECCO kWp Inverter is the next generation of super hybrid inverter with a 10400W MPPT and a rated AC output of 8.8kW resulting in a system that can generate sufficient energy in Winter months to offset usage and charge a connected battery. The inverter boasts additional features such as;
- Dual MPPT design
- Compatible with Lithium-ion batteries and Lead Acid batteries
- Up to 50kWh battery pack
- 5yr warranty as standard
- IP65 rated
- Anti-islanding protection
- Fully programmable power export
- Automatic switching from Grid-Tied to Off-Grid mode
- Up to 16 units with the same firmware can be paralleled
- Adding a Sunsynk battery to your existing inverter will extend the inverter warranty to 10 years
2 x GSL 10.24 G3~G8 Series ESS Battery System
As the leading vertically integrated manufacturer of lithium iron phosphate battery systems, GSL ENERGY has provided various battery solutions for nearly all kinds of ESS applications. Thanks to our self-developed core technology in cells/BMS/system design, GSL ENERGY has delivered more than 138+ countries serving 100,000+ users.
View/Download Component DataSheet
GSL’s power storage ESS adopts the latest HESS battery system. With rich experience and advanced techniques, this kind of home battery provides house battery backup for emergency use, it has the features of the fashionable design, high energy, high power density, long service life, and easiness of installation and expansion. Our ESS can provide comprehensive energy storage for residential, commercial and utility applications. Our Li-ion battery portfolio covers cells, modules, cabinets (indoor/outdoor) and containers, which offer customers excellent scalability and adaptability to a wide variety of requirements.
Warranties & Guarantees
Unprecedented savings, more economic security, greater energy autonomy for consumers and reduced carbon footprint.
End Of Proposal Version 1.01
